1.什么是线棒老化架？
线棒老化架是专用于老货测试时模拟产品在现实使用条件中涉及到的各种因素对产品产生老化的情况进行相应条件加强实验的过程，该实验主要针对塑胶材料，常见的老化主要有光照老化，湿热老化，热风老化。产品使用在户外常期受太阳光照，想要了解该产品在户外能够使用的寿命就要模拟太阳紫外光进行UV老化实验，当然实验的强度要比实际户外光照的强度要大很多，从而缩短测试时间，可以通过短时间的测试了解产品使用多少年后的老化情况。
同理如果产品使用在浴室等潮湿温度偏高的环境就要进行湿热老化，如果产品使用在机器的散热位置就要进行热风老化，当然根据产品出口到不同国家地区会有响应的测试标准：
2.线棒老化架的种类
灯管老化架、 电源老化架、led老化架、老化测试架、节能灯老化架、e17灯头老化架、开关电源老化架 深圳电源老化架、led电源老化架、led路灯老化架
3为什么要进行老化测试？有什么意义？
电子产品,不管是元件,部件,整机,设备,都要进行老化和测试.
老化和测试不是一个概念.先老化后测试.电子产品(所有产品都是这样)通过生产制造后,形成了完整的产品。已经可以发挥使用价值了,但使用以后发现会有这 样那样的毛病,又发现这些毛病绝大部分发生开始的几小时至几十小时之内,后来干脆就规定了电子产品的老化和测试,仿照或者等效产品的使用状态,这个过程由 产品制造者来完成.通过再测试。把有问题的产品留在工厂,没问题的产品给用户,以保证买给用户的产品是可靠的或者是问题较少的.这就是老化测试的意义。
恒川货架厂线棒老化架主要特点：
◆主体采用钣金结构、烤瓷漆、带脚轮、方便移动；
◆双边工作式，分层结构设计、负载为抽屉式安装，方便维护与更换；
◆老化产品数量可根据产品负载大小来定制，现有规格为45组（200W）、60组（150W）、98组（100W）、128组（75W）、200组（30W）；
◆老化车自带工作电压表、电流表和监控功能，含工作指示灯，测量指示灯和测量开关，按下测量开关，即可显示当前组老化电压、电流值；
◆线棒老化车自带保护装置，超负载工作时可自动切断电源。
技术参数：
◆测量电压：AC/DC0-30V/50V/100V
◆电压分辨率：10mV
◆测量电流：AC/DC0-10A/20A/30A
◆电流分辨率：10mV
◆电流稳定性及误差：<20mA
◆测量功率：100W/200W/300W
◆测量精度：0.2%
1. What is wire rod aging rack?
Wire rod aging rack is specially used in the testing of old goods to simulate various factors involved in the actual use conditions of products to conduct the corresponding condition strengthening experiment on the aging of products. This experiment is mainly aimed at plastic materials. Common aging mainly includes light aging, damp and heat aging, and hot air aging. Products used in outdoor period by the sun, want to know the product to be able to use in the outdoor life is simulated solar ultraviolet UV aging experiment, the strength of the experiment, of course, outdoor light intensity is much larger than it actually is, so as to shorten the testing time, can pass the test for a short period of time to understand aging products use many years later.
In the same way, if the product is used in an environment with high humidity temperature, such as the bathroom, it will undergo damp and heat aging; if the product is used in the heat dissipation position of the machine, it will undergo hot wind aging. Of course, according to the test standards of products exported to different countries and regions, there will be responses:
2. Type of wire rod aging rack
Lamp aging rack, power aging rack, led aging rack, aging test rack, energy-saving lamp aging rack, e17 lamp holder aging rack, switching power aging rack shenzhen power aging rack, led power aging rack, led street lamp aging rack
3. Why do we need the aging test? What's the point?
Electronic products, whether components, components, complete machines, equipment, are aging and testing.
Aging and testing are not the same thing. Aging first, testing later. Electronics (as with all products) are manufactured to form a complete product. Already can play a use value, but use after discovery will have this kind of problem, and found that for the most part these faults occur in the first few hours to a few hours, then simply defines aging and testing of electronic products, to simulate or equivalent products using state, this process is done by the manufacturer. Through the test again. Leave the defective products at the factory and give the defective products to the users to ensure that the products bought to the users are reliable or less problematic. This is the significance of aging test.
Main features of aging rack of wire rod in hengchuan shelf factory:
◆ the main body adopts sheet metal structure, ceramic paint, casters, easy to move;
◆ double-sided operation, layered structure design, load for drawer type installation, easy maintenance and replacement;
◆ the quantity of aging products can be customized according to the load size of products. The existing specifications are 45 groups (200W), 60 groups (150W), 98 groups (100W), 128 groups (75W), and 200 groups (30W).
◆ the aging car comes with its own working voltmeter, ammeter and monitoring function, including working indicator light, measuring indicator light and measuring switch. Press the measuring switch to display the aging voltage and current value of the current group;
◆ wire rod aging car with protective device, can automatically cut off the power supply when working over load.
Technical parameters:
◆ measurement voltage: AC/ dc0-30v /50V/100V
◆ voltage resolution: 10mV
◆ measuring current: AC/ dc0-10a /20A/30A
◆ current resolution: 10mV
Current stability and error: <20mA
◆ measuring power: 100W/200W/300W
◆ measurement accuracy: 0.2%
